Double floor escutcheon

TABLE

Characteristic	Description
Purpose	For the aesthetic finish of the outlet of ALUPLAST and copper (Cu) fi 16 pipes from the underfloor distribution to the radiator with an H-valve in a two-pipe underfloor distribution system. It covers all imperfections in the floor finish around the pipes and, by means of a spring tab, allows correction of center-distance errors of the installed pipeline of +/-5 mm for the double version, i.e. a minimum center distance of 43 mm and a maximum of 53 mm. In the double/accordion version, it additionally covers center-distance corrections of the installed pipeline through the accordion movement, from a minimum center distance of 26 mm to a maximum of 62.
Properties	The parts are made of high-quality PP copolymer with added additives and color, using the injection molding process, which gives the product elasticity and thermal stability for use in the temperature range from -10 to +118 °C. The product design allows installation on an already completed pipeline.
Dimensions	According to the drawing.
Color	White or beige
Packaging	According to the attached table. Basic packaging in a PE bag, bulk packaging in a cardboard box.

PRODUCT DRAWING
